media extender dvi 2-way

◦ 2 self-sufficient Dual-Link DVI-D connections per unit


◦ 2 gigabit network ports via Neutrik Ethercon connector


◦ fast lock connections for trussmount hook


◦ 4 safety eyelets arround the housing


◦ transmitter in 19“ housing (1U)


◦ connection between transmitter and receiver via motionfiber 4-way fiber cable.
   Integration into an existing fiber system is also possible


◦ power supply via Neutrik PowerCon


◦ status LED for every DVI connection


◦ DVI-D standard 1.0


◦ resolutions up to 1920x1200@60Hz


◦ latency-free video transmission via fiber
  (SM up to 20km | MM up to 2km)


◦ EDID transparent


◦ HDCP transparent

◦ available as Neutrik OpticalCON QUAD connector
